Heated Soak Tank to Clean Carbon from Baking Pans Pizza Pans with Chemical

Basic Information
Place of Origin: China
Brand Name: AG SONIC
Certification: CE
Model Number: TS-168
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: 1unit/wooden case
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 300units/month
Product Name: Heated Soak Tank Tank Size: 655*410*625mm
Usage: Kitchen Cleaning Heating: Optional
Ultrasonic: Optional Packing: Wooden Case
High Light:

stainless steel soak tank


oven cleaning dip tank


Heated Soak Tank to Clean Carbon from Baking Pans Pizza Pans with Chemical


This tank is perfect for larger commercial kitchens such as hotels. Wider than the Tallboy Tank, it gives you further flexibility to clean larger trays and equipment. It features an easy to load basket system with lock in pins and safety gas assisted lid.


We pride our self on safety. Some of our features include:



One person operation with hand held control

Load bearing of 260 kg

OH&S compliant, making the workpalce safer

Easily load up to 15 range hood filters

Neoprene seal under the lid keeping the heat in and reducing power costs.

Food grade stainless steel with a double insulated frame allowing for temperature adjustments.


Safety features

Gas strut lid, making opening and closing safer

Heavy duty lockable castors

Automatic overload cut off

Limit switch



Model Volume Tank size (mm) Unit Size (mm) Basket size (mm)
TS-168 168L 655*410*625 755*510*785 605*390*595
TS-211 211L 750*450*625 850*550*785 700*430*595
TS-258 258L 890*480*605 990*580*800 840*460*575
TS-274 274L 840*480*680 940*580*875 790*460*650
TS-338 338L; 1080*460*680 1180*560*875 1060*440*650
TS-483 483L 1365*520*680 1465*620*875 1315*500*650


Small tank: suitable for canopy fitlers, grill tops, pans and small trays.

Medium tank(popular size): suitable for busy medium sized pans and large trays & oven racks.

Large tank: suitable for greasy filters, pots, baking trays, etc,

From 10 gallons to 90 gallons We also offer custom sizes for larger applications.

Different tank size is available,We also offer custom sizes for larger applications.




Drain Down Regular Floor Drain

Screw the Adaptor into the ball valve.

Connect the hose to the adaptor.Place the end of the hose into the floor drain.

Open the valve slowly.

When the solution has drained, remove the basket and clean in the sink.Collect any sludge that accumulates in the trough at the bottom of the unit.Rinse the inside of the unit with clean water until it is thoroughly clean.

Close the ball valve.

Replace the basket.

Fill the unit with clean fresh water (preferably hot) to the -H2O- fill line.

Add the appropriate number of boxes of CarbonZyme by spreading evenly.

Plug the unit in and switch on!


Our soak tank can effectively clean virtually any items in your kitchen, including, but not limited to:

This system ensures that your kitchen items will always come out clean and shining-bright at the start of every day.

Soak Tank Service Program


Say Goodbye To Difficult Cleaning

Are you tired of wasting labor on hard-to-clean kitchen items such as utensils, racks, grates, pans, pots, and hood filters? Thankfully, our fully certified and experienced technicians have come up with a way to resolve this! Our Soak Tank Service Program offers a solution that’s specifically designed for soaking those hard-to-clean kitchen utensils and dishware. Simply place your dirty kitchen items in the soak tank overnight, remove them in the morning, and rinse.


How to use ?

Heated Soak Tank to Clean Carbon from Baking Pans Pizza Pans with Chemical 0

Heated Soak Tank to Clean Carbon from Baking Pans Pizza Pans with Chemical 1
